AT-SB32-22
INDUSTRIAL 32mm (1-1/4") Crown Pneumatic Side Post Stapler
If you want to achieve one of the strongest and safest closures of cartons, our foot operated carton stapler series is an obvious choice. The SB Series- pneumatic /mechanical side arm stapler is designed for professional packaging jobs. Capacity is increased significantly since the machine is equipped with a pneumatic actuator.
- Carton Box Sealing
- Bottom of Single or Double-Walled Carton Sealing
- Packaging
APPLICATIONS
FEATURES
DEPTH OF CLINCH AND PENETRATION ADJUSTABLE
Fully adjustable according to your sealing needs
SAFETY PRIORITIZED
Equipped with a safety foot pedal
MANUAL VERSION AVAILABLE (MT Series)
Provides flexibility when there is a lack of compressed air
PRODUCTION GRADE
Ideal for high volume production
HIGH SPEED OPERATION
50~100 carton bottoms per hour
NOISE MINIMIZED
Low noise engine
TOOL SPECIFICATION
| Weight | 29 kgs (63.9 lbs) |
|---|---|
| Height | 1245mm (49") |
| Width | 600mm (23.6") |
| Length | 830mm (32.7") |
| Operating Pressure | 5.5~6 bar (80~86 psi) |
| Driving Power (in-lbs @100psi) | Clinch Type Tool N/A |
| Air Consumption (L/sec @90psi) | 2.0 (4.2 cfm) |
FASTENER SPECIFICATION
| Type | Pneumatic Side Arm Stapler C |
|---|---|
| Loading Capacity | 200 |
| Shank Type | Smooth |
| Staple Length | 15, 18, 22mm (5/8", 3/4", 7/8") |
| Staple Crown Width | 32mm (1-1/4") |
| Staple Wire Dia. | 0.9x1.9mm (0.035"x0.075") |
