RCC-19-SWC
INDUSTRIAL Bostitch SWC type Pneumatic Roll Carton Stapler
The RCC carton closer range is designed with a capacity of 1000 staples for high volume production. The tools have a penetration adjustment which in combination with the robust bases and light weight bodies help provide a great user experience.
- High Volume Production
- Carton Box Sealing
- Packaging
APPLICATIONS
FEATURES
DEPTH OF CLINCH AND PENETRATION ADJUSTABLE
Fully adjustable according to your sealing needs
ERGONOMICALLY SOUND
Light weight and well-balanced
PRODUCTION GRADE
Ideal for high volume production
COMPACT YET HIGH LOAD
Roll-type magazine takes 1000 staples per load
ALL METAL CONSTRUCTION
Endures rough production work environments
NOISE MINIMIZED
Low noise engine
TOOL SPECIFICATION
| Weight | 2.4 kgs (5.2 lbs) |
|---|---|
| Height | 230mm (9.1") |
| Width | 115mm (4.5") |
| Length | 233mm (9.2") |
| Operating Pressure | 5~6.9 bar (70~100 psi) |
| Driving Power (in-lbs @100psi) | Clinch Type Tool N/A |
| Air Consumption (L/sec @90psi) | 0.5 (1.05 cfm) |
FASTENER SPECIFICATION
| Type | Bostitch SWC type Carton Staples |
|---|---|
| Loading Capacity | 1000 |
| Shank Type | Smooth |
| Staple Length | 15&18mm (5/8"&3/4") |
| Staple Crown Width | 34mm (1-3/8") |
| Staple Wire Dia. | 0.9x1.9mm (0.035"x0.075") |
